PA20° PCD 180mm β15° Disk Type Gear Shavng Cutter with Module m1.25~m6
2022-05-20 09:09:32
jiangxingTools
1840
PA20° PCD 180mm β15° Disk Type Gear Shavng Cutter with Module m1.25~m6
Material: HSS M2, M35
Module: m1.25, m1.5, m1.75, m2, m2.25, m2.5, m2.75, m3, m3.25, m3.5, m3.75, m4, m4.5, m5, m5.5, m6
Tooth profile：GB standard
Accuracy: class A
Bore: 63.5mm Width: 20mm
