Tip Chip Thickness for Hobs
The tip chip thickness is an important criterion for hob design and optimization. the tip chip thickness is the theoretical maximum chip thickness which can be removed by the tooth tips of the hob.
The following hob characteristics and cutting parameters are taken into account during calculation of the tip chip thickness:
1), module
2), number of teeth
3), helix angle
4), profile displacement
5), cutter diameter
6), number of gashes
7), number of starts
8), axial feed
9), cutting depth
