Involute Spline Gear Hob with DIN 5482
hobs for spline shafts with involute flanks previously DIN 5482
30° pressure angle
quality grade A to DIN 3968
single start, right-handed
with keyway
For cutting spline shafts as per ANSI, DIN Standards, Involute Spline hobs have a stud tooth depth for cutting all types of standard and non-standard involute splines where as straight spline hobs are used for cutting parallel splines and are manufactured in single or multi start design with pressure angles 20°, 30°, 37.5° and 45°.
